$22.89 excl. VAT

AMPS Base

12 mm Round Bar Crossbar AMPS Interface Adapter (M5 Threaded)

The critical mechanical bridge for adventure cockpits. Clamps onto 12 mm crossbar shafts to provide an industry-standard AMPS 30 × 38 mm mounting platform in both portrait and landscape.

Throw out flimsy plastic ball mounts that droop on the first rocky descent. The AMPS M5 v2 is machined from solid billet aluminum, clamping rigidly to the 12 mm round bars found on rally towers, factory GPS bars, and our custom cockpit brackets.

Hardware & Specs:

  • 12 mm Clamp: Direct fit on all 12 mm round navigation crossbars and rally stays.
  • Lightweight Holder Ready: Drilled and tapped with M5 threads specifically to mount the Carpe Iter Lightweight Holder without extra hardware.
  • Complete Hardware Kit: Includes 4× M5×35 mm stainless hex bolts, 4× washers, and the matching hex key so you can bolt it straight on.
  • Modularity: Pairs cleanly with our Medium Bracket and rally navigation towers.

In stock (can be backordered)

[ APPLICATION_DATA // 12 MM SHAFT INTERFACE ]
AMPS M5 V2

Universal 12 mm Crossbar AMPS Interface for Lightweight Holder and GPS Navigation.

The AMPS M5 v2 is a CNC-machined billet aluminum mounting bracket that bridges round 12 mm crossbars to the universal AMPS 4-hole pattern. Designed as the core mechanical link for adventure cockpits, it clamps securely around 12 mm GPS mounting bars (standard equipment across Yamaha Ténéré 700, KTM Adventure, BMW GS, and aftermarket rally navigation towers).

The mounting face incorporates symmetrical 30 × 38 mm AMPS hole centers drilled for M5 fasteners, allowing riders to orient their device cradles in either portrait or landscape orientation without changing brackets.

Specifically tailored to mate directly with the Carpe Iter Lightweight Holder, it provides a clean, vibration-resistant mount without requiring intermediate ball-mounts or oversized bracketry.

INCLUDED MOUNTING HARDWARE
  • ■
    4× M5 × 35 mm stainless steel hex screws (sized for Lightweight Holder clamp stack)
  • ■
    4× M5 stainless steel flat washers
  • ■
    1× Matching Allen (hex) key for cockpit field servicing

TORQUE & INSTALLATION GUIDANCE
* Even Clamping: When tightening the clamp bolts around the 12 mm shaft, tighten the screws alternately in small increments to ensure an even clamping gap on both sides of the shaft.
* Device Alignment: Check that your navigation holder or tablet does not contact the motorcycle windshield at full steering lock or when traveling through rough terrain.
STANDARD: 12 MM SHAFT // AMPS 30X38 M5
VALIDATION: CARPE ITER CERTIFIED MOUNTING

[ PHYSICAL_PARAMETERS // SPECS ]
MOUNTING ADAPTER SPEC
Product Classification12 mm Round Bar Crossbar AMPS Interface Adapter
Hole Pattern StandardIndustry-standard AMPS 30 × 38 mm (portrait & landscape orientation)
Screw Hole SizingDrilled for M5 machine screws
Shaft Fitment12 mm round bar / navigation crossbar tubing
Material & Surface TreatmentCNC-machined aluminum with durable black anodized finish
Included Hardware Pack4× M5 × 35 mm screws, 4× flat washers, 1× Allen key
Cradle CompatibilityDirect fit for Carpe Iter Lightweight Holder and third-party AMPS cradles
CLAMP: 12 MM DIAMETER SHAFT
VALIDATION: CARPE ITER CERTIFIED HARDWARE
